50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device

Large Image : 50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device

Product Details:

Place of Origin:	China
Brand Name:	Adcol
Certification:	ISO9001, CE
Model Number:	ATL050-12/24VDC

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotation
Packaging Details:	Solid Carton Packaging
Delivery Time:	3-4 Weeks
Payment Terms:	T/T, Paypal
Supply Ability:	10kPcs/Month

Contact Now

50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device

Description

P/N:	ATL050-12/24VDC	Cooling Method:	Air To Fluid
Cooling Objective:	Purified Water	Cooling Objective Contact Part:	Aluminum, Partially Copper
Cooling Capacity 50W Fan Input Voltage:	50W	Fan Input Voltage:	12/24VDC
Peltier Input Voltage:	12/24VDC	Rated Consumption Current:	8.7A /4.4A
Starting Current:	10.2A /5.1A	Working Humidity:	Below 80%
Max Ambient Temperature:	60 Degree	Overheat Protection:	No
Electrical Connection:	Screw	Noise:	39DB
Site Of Use:	Indoor	Outer Diameter Of Pipe Connecting Port:	Dia 9.5mm
Dimensions:	160x120x84mm	Mass Of Main Unit:	Est. 1.5kgs

Adcol Peltier Thermal Cooler is your perfect choice for any Industrial, Commercial or Home application. Adcol is a well-known brand name from China and all of our Peltier Thermoelectric Modules have been certified with ISO9001 and CE.

The solid carton packaging ensures secure delivery and payment terms include T/T and Paypal. We guarantee a supply ability of 500pcs per month.

50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device

1.Product Introduction

The ATL050-24 Thermoelectric air to Liquid are designed for electronic liquid cooling. They can

cool to 72˚F below ambient or maintain ambient temperatures while removing up to 50W. These

models are available in 12 or 24 VDC configurations.

50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device 0

2.Performance Curve

50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device 1

3.Product drawing

50W Thermoelectric Liquid Cooler For Laser Machinery Medical Device 2
