1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot

1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot
1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot

Large Image :  1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot

Product Details:
Place of Origin: China
Brand Name: Adcol
Certification: ISO9001 , CE
Model Number: ATL1000-24VDC
Payment & Shipping Terms:
Minimum Order Quantity: 1EA
Price: Negotiation
Packaging Details: Solid carton packaging
Delivery Time: 3 - 4 weeks
Payment Terms: T/T , Paypal
Supply Ability: 100Pcs/Month

1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot

Description
P/N: ATL1000-24VDC Operating Temperature Range: -30~70°C
Storage Temperature Range: -40~90°C Maximum Material Stress: 350 Bar
Nominal/Max Voltage: 24,Vmax=28VDC Peak Current: 54A
Operating Current: 48A Maximum Cooling Power: 1080W
Maximum Heating Power: 2000W Radiating Method: Air Force
Weight: 48kg Overall Dimension: L840*W253*H222
Highlight:

1000W glue cooling system

,

thermoelectric adhesive temperature control

,

Peltier module for gluing robot

Adcol Peltier Thermal Cooler is your perfect choice for any Industrial, Commercial or Home application. Adcol is a well-known brand name from China and all of our Peltier Thermoelectric Modules have been certified with ISO9001 and CE.

The solid carton packaging ensures secure delivery and payment terms include T/T and Paypal. We guarantee a supply ability of 500pcs per month.





1000W glue solution cooling system



  • This product is a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot. It is used to heat or cool the adhesive or sealing materials to achieve the optimal application conditions.



  • This product uses high-performance semiconductor cooling plates to heat or cool the coated  medium,thereby ensuring that the coated medium is used within the set temperature range.



  • The cooling medium is mainly PVC glue used for vehicle painting. If it is needed to control the  temperature of other media, it is necessary to communicate with the manufacturer of the condenser  ​​ in advance for confirmation.



1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 0





Technical parameters



Item Unit Value
Operating temperature range -30~70
Storage temperature range -40~90
Maximum material stress Bar 350
Material entry specification   G 1/2
Material export specifications   G 1/2
Applying voltage VDC 24,Vmax =28VDC
Peak current A 54
Operating current A 48
Maximum cooling power W 1080
Maximum heating power W 2000
Temperature sensor   PT100,3线
Heat dissipation method   Air-cooled
Overall dimension mm L840*W253*H222
Weight   45KG

1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 11000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 2





1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 3



1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 4



1000W glue solution cooling system-a customized solution designed for controlling the temperature of the adhesive liquid in the gluing robot 5
