Product Details:
|
| Feature: | Fast Cooling And Heating With Precise Temperature | Control The Liquid In Bath: | ±0.05︒C |
|---|---|---|---|
| Cool Objective: | Liquid | Weight(kg): | 25 |
| High Light: | thermoelectric cooling unit,tec thermoelectric cooler |
||
Semiconductor Liquid Tank Water Cooling Peltier Bath
Adcol recirculating bath (tank) designed per customer request. ARB is used for LED manufacturing evaporating system , control the liquid in bath for ±0.05︒C precision.
ART is widely used in every industry , maintain test temperature in ±0.5︒C range . We also could design per customer request .
| ARB/T Part No. | Capacity(W) | Cool objective | Precision Temp. | Weight(kg) | Dimension(cm) | Bath Volume(L) |
| ART-100-220VAC-A-00 | 100 | Air | ±0.5︒C | 17 | W73xD45xH50 | 40 |
| ARB-320-220VAC-A-00 | 320 | Liquid | ±0.04︒C | 25 | W35xD51xH55 | 39 |
Features
- Fast cooling and heating with precise temperature
- Easy to operate
- Environmentally friendly and refrigerant-free
- Programmable Digital Temperature Controller
- System Error Monitor and alarm
- High reliability
Application
Evaporation of chemicals for MOCVD
Temperature control of diffusion gas
Thermal test with immersion
Indirect temperature control of chemicals and liquid with high viscosity
Application Examples:
